Description
Standards 2G,3G and 4G
Frequency 698-960, 1710-2170, 2500-2700
VSWR ~2.6:1, ~2.2:1, ~1.4:1
Efficiency (%) ~30.9, ~35.6, ~38.4
Peak Gain (dBi) ~1.9, ~1.9, ~2.2
Impedance (Ohm) 50
Polarisation Linear
Max. Input Power (W) 25
Standards 2G,3G and 4G
Frequency 698-960, 1710-2170, 2500-2700
VSWR ~2.5:1, ~2.3:1, ~1.5:1
Efficiency (%) ~31.8, ~35.6, ~39.2
Peak Gain (dBi) ~2.3, ~1.9, ~2.4
Impedance (Ohm) 50
Polarisation Linear
Max. Input Power (W) 25
Standards GPS/QZSS/Galileo/GLONASS
Frequency 1575.42, 1598-1606
VSWR ~1.4:1
Impedance (Ohm) 50
Polarisation RHCP
Active Gain (dB) 28 @ 2.7 V
Saw Filter Type Pre-Filter
Voltage (V) 1.5 – 3.6
Noise Figure (dB) 1.5 Typ
Current Consumption (mA) 9 Typ
Power Consumption (mW) 24.3 Typ
ESD Protection (kV) 2
